1200Mbps LTE Wireless EasyMESH Router

Model:RE1200R4GCMs-2T2R-V1ab

  • High performance wireless speeds up to 1200Mbp
  • With LTE-based Internet connection (embedded LTE module), users can access the Internet while sitting on anywhere.
  • Seamlessly connects you to the strongest signal as you move from room to room.
  • MU-MIMO technology creates a powerful, fast, and highly efficient Wi-Fi network
  • Automatically directs your devices to the optimal wireless band
  • Pairing been completed in advance, so you just need to plug them in and EASYMESH network ready for use.
  • Support WPS configuration with 1-Push button
  • Keep your kids safe by blocking specific devices and websites, and set a schedule to turn off wireless networks or restrict access.
  • One wireless network name (SSID) for your entire environment, no matter where you are.
  • A user friendly APP helps user to set up EasyMESH network quickly.


Specification

Wireless Standards IEEE 802.11b/g/n (2.4GHz) ; IEEE 802.11ac (5GHz)
Support EASYMESH Technology
Data Rate 300Mbps (2.4GHz) ; 866Mbps (5GHz)
Interface 1 * SIM socket
1 * DC Power Jack
1 * WAN:10/100/1000Mbps Auto MDI/ MDIX RJ-45 Ethernet Port
2 * LAN:10/100/1000Mbps Auto MDI/ MDIX RJ-45 Ethernet Port
WAN IP Assignment Static IP / DHCP client / PPPoE client
LTE Specification WCDMA : Band 1/3/5/8
FDD-LTE : Band1/3/5/7/8/20/28/321
TDD-LTE : Band 38/40/41 (2555~2655MHz)
LTE 2DLCA(Cat6) : B1+B1/3/5/7/8/20/28, B3+B3/5/7/8/20/28, B5+B7,B7+B7/8/20/28, B38+B38, B40+B40, B41+B41, B20+B321
GNSS(RESERVED): GPS/GLONASS/BeiDou/Galileo/QZSS
Features IGMP snooping and IGMP proxy
IPv4/IPv6 dual stacks function
VPN pass through
MU-MIMO
Band Steering
Beamforming
Management - HTTP Web-based Configuration
Remote Management - TR069 / HTTP
Support Mobile App to set up EASYMESH network quickly
Button WPS, Reset
LED Power, LTE, WLAN, WPS, LAN, WAN, WiFi Strength
Antenna 2 x LTE Internal Antennas
2 x 2.4Ghz Internal Antennas + 2 x 5Ghz Internal Antennas
Wireless Security 64 / 128-bit WEP,WPA, WPA2, WPS
Operating Environment Operating temperature: 0 – 40°C
Storage temperature: -20 – 70°C
Humidity: 20 – 95%RH non-condensing
Dimensions 87 (L) × 87 (W) × 162(H) mm
Package 1pcs LTE EasyMESH WiFi Router
1pcs Power Adaptor
1pcs Quick Installation Guide
1pcs Ethernet Cable (RJ-45)
